Engine Type: V Twin
Displacement: 47.8 cu. in. (783 cc)
Bore and Stroke: Bore: 3.35 in. (85 mm); Stroke: 2.72 in. (69 mm)
Cooling: Liquid
Compression Ratio: 10.7:1
Fuel System: Gas
Front Suspension: Double A-Arm
Front Brakes: Dual Hydraulic Disc
Front Tire: Maxxis® Bighorn: 27 x 9-14
Rear Suspension: Independent
Rear Brakes: Sealed Oil Bath Multi-Disc
Rear Tire: Maxxis® Bighorn: 27 x 11-14
Wheelbase: 88.2 in. (2240.3 mm)
Front Travel: 10.7 in. (271.8 mm)
Rear Travel: 10 in. (254 mm)
Ground Clearance: 11.2 in. (284.5 mm)
Fuel Capacity: 7.9 gal. (29.9 L)
Box Capacity: 249 lbs. (112.9 kg.)
Towing Capacity: 1300 lb. (589.7 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Standard
