Engine Type: Single-Cylinder
Displacement: 5.5 cu. in. (90 cc)
Bore x Stroke: Bore: 1.79 in. (45.5 mm); Stroke: 2.17 in. (55.2 mm)
Cylinders: 1
Engine Cooling: Air
Fuel System: Gas
Starting System: Electric / Pull
Front Suspension: Independent A-Arm
Front Brake Type: Dual Drum
Front Tires: Dunlop® AT 19 X 7-8
Rear Suspension: Swing Arm
Rear Brake Type: Drum
Rear Tires: Dunlop® AT 19 X 7-8
Frame: Steel
Fuel Capacity: 1.6 gal. (6 L)
Ground Clearance: 5.9 in. (150 mm)
Machine Dimensions (LxWxH): L: 59.3 in. (1505 mm); W: 34.4 in. (875 mm); H: 36 in. (915 mm)
Wheelbase: 39.6 in. (1005 mm)
Drive Train: Continuously Variable (CVT)
