Engine Type: Single-Cylinder
Displacement: 42.4 cu. in. (695 cc)
Bore x Stroke: Bore: 4.02 in. (102 mm); Stroke: 3.35 in. (85 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent Double A-Arm
Front Travel: 6.9 in. (175.3 mm)
Front Brake Type: Dual Hydraulic Disc
Front Tires: AT 26 X 8-14
Rear Suspension: Independent Double A-Arm
Rear Travel: 7.4 in. (188 mm)
Rear Brake Type: Hydraulic Disc
Rear Tires: AT 26 X 10-14
Frame: Steel
Dry Weight: 800.3 lb. (363 kg.)
Towing Capacity: 1029 lb. (466.8 kg.)
Fuel Capacity: 5.55 gal. (21 L)
Ground Clearance: 10.7 in. (271.8 mm)
Machine Dimensions (LxWxH): L: 84.2 in. (2138.7 mm); W: 49 in. (1244.6 mm); H: 49.2 in. (1249.7 mm)
Wheelbase: 51.1 in. (1297.9 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
