Engine Type: Single-Cylinder
Displacement: 5.5 cu. in. (90 cc)
Bore x Stroke: Bore: 1.85 in. (47 mm); Stroke: 2.04 in. (51.8 mm)
Cylinders: 1
Engine Cooling: Air
Fuel System: Gas
Starting System: Electric / Kick
Front Suspension: A-Arm
Front Travel: 5 in. (127 mm)
Front Brake Type: Dual Sealed Drum
Front Tires: AT 19 X 7-8
Rear Suspension: Swing Arm
Rear Travel: 5.7 in. (144.8 mm)
Rear Brake Type: Sealed Drum
Rear Tires: AT 18 X 9-8
Frame: Steel
Fuel Capacity: 1.7 gal. (6.4 L)
Ground Clearance: 4.1 in. (104.1 mm)
Machine Dimensions (LxWxH): L: 61.5 in. (1562.1 mm); W: 40.6 in. (1031.2 mm); H: 39.6 in. (1005.8 mm)
Wheelbase: 40.6 in. (1031.2 mm)
Drive Train: Continuously Variable (CVT)
