Engine Type: Horizontal In-line
Displacement: 51.2 cu. in. (840 cc)
Bore x Stroke: Bore: 3.35 in. (85 mm); Stroke: 2.91 in. (74 mm)
Cylinders: 2
Engine Cooling: Liquid
Carburetion: Fuel Injected
Brake Type: Hydraulic Disc
Drive Clutch: P-22 / TEAM BOS
Driven Clutch: Continuously Variable (CVT)
Front Suspension: Independent A-Arm
Front Travel: 9 in. (228 mm)
Rear Travel: 16.5 in. (419 mm)
Ski Type: Plastic
Ski Stance: Min: 39 in. (991 mm); Max: 41 in. (1041 mm)
Track Type: Cobra Track
Track Dimensions: W: 20 in. (508 mm); L: 155 in. (3937 mm); Lug Height: 1.5 in. (38.1 mm)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
Fuel Capacity: 12.6 gal. (47.7 L)
Dry Weight: 677 lb. (306 kg.)
Windshield: Standard
Electric Start: Electric / Pull
Reverse: Yes
Mirrors: Standard
