350.00 setup Engine Type: Parallel Twin
Displacement: 56.4 cu. in. (925 cc)
Bore and Stroke: Bore: 3.66 in. (93 mm); Stroke: 2.68 in. (68 mm)
Cooling: Liquid
Fuel System: Gas
Front Suspension: Independent Double A-Arm
Front Brakes: Hydraulic Disc
Front Tire: Maxxis® Rampage Fury: 32 x 10-15
Rear Suspension: Independent
Rear Brakes: Hydraulic Disc
Rear Tire: Maxxis® Rampage Fury: 32 x 10-15
Dry Weight: 2024 lb. (918 kg.)
Wheelbase: 96 in. (2440 mm)
Front Travel: 27 in. (686 mm)
Rear Travel: 28.3 in. (719 mm)
Ground Clearance: 16 in. (406 mm)
Fuel Capacity: 12 gal. (45.4 L)
Box Capacity: 300 lbs. (136.1 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
