* Prices shown are based on the manufacturer's suggested retail price (MSRP) and is subject to change without notice. Website price excludes destination charges, setup fees, optional accessories, applicable taxes, license and document fees. Some vehicles are shown with optional accessories which are not included in the price. All sale prices include any factory incentives, factory rebates, and dealer discounts. Engine Type: 2-stroke single with exhaust power valve (KIPS)
Displacement: 112cc
Bore and Stroke: 52.5 x 51.6mm
Cooling: Liquid
Compression Ratio: 9.9:1 (Low speed)/8.6:1 (High speed)
Fuel System: 28mm Keihin carburetor
Ignition: CDI with digital advance
Front Suspension: 36mm inverted telescopic cartridge fork with 20-way compression damping/10.8 in. travel
Front Brakes: Single 220mm petal disc with dual-piston caliper
Front Tire: 70/100-19
Rear Suspension: Uni-Trak® gas charged shock with piggyback reservoir with 24-way compression and 21-way rebound damping plus adjustable spring preload/10.8 in. travel
Rear Brakes: Single 184mm petal disc with single-piston caliper
Rear Tire: 90/100-16
Dry Weight: Curb Weight: 169.7 lb.
Fuel Capacity: 1.32 gal.
Wheelbase: 51.6 in.
Ground Clearance: 13.0 in.
Seat Height: 34.3 in.
Trail: 4.3 in.
Rake: 29 deg.
Transmission: 6-speed, return shift, with wet multi-disc manual clutch
Final Drive: Chain
Colors: Lime Green
