FINANCING AVAILABLE - CALL SALES @ 570-584-3842 FOR MORE INFORMATION Engine Type: 4-stroke, single cylinder, SOHC
Displacement: 124 cc
Bore and Stroke: 2.244 in. x 1.921 in. (57.0 mm x 48.8 mm)
Cooling: Air
Compression Ratio: 9.5:1
Fuel System: Mikuni VM20SS, single carburetor
Ignition: Electronic ignition (CDI)
Front Suspension: Telescopic, coil spring, oil damped
Front Brakes: Disc brake, single rotor
Front Tire: 70/100-19 M/C 42M, tube type
Rear Suspension: Link type, coil spring, oil damped
Rear Brakes: Drum brake
Rear Tire: 90/100-16 M/C 52M, tube type
Dry Weight: Curb Weight: 196 lb. (89.0 kg)
Fuel Capacity: 1.3 US gal. (4.8 L)
Wheelbase: 50.0 in. (1270 mm)
Ground Clearance: 11.4 in. (290 mm)
Seat Height: 32.0 in. (805 mm)
Transmission: 5-speed constant mesh
Final Drive: Chain, DID 428HG, 130 links
Colors: Champion Yellow No. 2
