Engine Type: Single-Cylinder
Displacement: 34.6 cu. in. (567 cc)
Bore and Stroke: Bore: 3.9 in. (99 mm); Stroke: 2.9 in. (73.6 mm)
Cooling: Liquid
Compression Ratio: 10:1
Fuel System: Gas
Front Suspension: McPherson Strut
Front Brakes: Hydraulic Disc
Front Tire: Carlisle 489: 25 x 8-12
Rear Suspension: Independent Double A-Arm
Rear Brakes: Hydraulic Disc
Rear Tire: Carlisle 489: 25 x 10-12
Dry Weight: 1070 lb. (486 kg.)
Wheelbase: 79 in. (2007 mm)
Front Travel: 9 in. (229 mm)
Rear Travel: 10 in. (254 mm)
Ground Clearance: 10.5 in. (267 mm)
Fuel Capacity: 9 gal. (34.1 L)
Box Capacity: 800 lbs. (363 kg.)
Towing Capacity: 1500 lb. (680 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
