Engine Type: 4-Stroke, single cylinder, DOHC
Displacement: 652cc
Bore and Stroke: 100.0 x 83.0mm
Compression Ratio: 9.8:1
Fuel System: DFI w/40mm Throttle Body
Ignition: Cdi
Transmission: 5-speed, return shift with wet multi-disc manual clutch
Final Drive: Sealed Chain
Front Suspension: 41mm telescopic fork/ 7.9 in. travel
Rear Suspension: Uni-Trak® gas charged shock with piggyback reservoir with adjustable rebound damping and spring preload/ 7.3 in. travel
Front Brakes: Single 300mm disc with 2-piston calipers, ABS
Rear Brakes: Single 240mm disc with single-piston caliper, ABS
Front Tire: 90/90-21
Rear Tire: 130/80-17
Wheelbase: 60.6 in.
Seat Height: 34.3 in.
Rake: 30.0 deg. deg.
Trail: 4.8 in.
Fuel Capacity: 6.1 gal.
Dry Weight: Curb Weight: 487.1 lb.
Colors: Cypher Camo Gray
