Engine Type: OHV longitudinally mounted single-cylinder four-stroke
Displacement: 229cc
Bore x Stroke: 68.5 mm x 62.2 mm
Engine Cooling: Air
Fuel System: 22 mm carburetor
Starting System: Electric with auxiliary recoil
Front Suspension: Independent double-wishbone
Front Travel: 5.1 in.
Front Brake Type: Dual sealed hydraulic drum
Front Tires: 22 x 7-11
Rear Suspension: Swingarm with single shock
Rear Travel: 4.9 in.
Rear Brake Type: Sealed mechanical drum
Rear Tires: 22 x 10-9
Dry Weight: Curb Weight: 441 lb.
Fuel Capacity: 2.4 gal., including 0.6-gal. reserve
Ground Clearance: 6.0 in.
Machine Dimensions (LxWxH): 75.0 in. x 40.7 in. x 42.1 in.
Wheelbase: 44.5 in.
Final Drive: Direct rear driveshaft
Transmission: ESP Five-speed with Reverse
Colors: Red, Green
