Engine Type: Dry-sump single-cylinder four-stroke
Displacement: 644cc
Bore and Stroke: 100mm x 82mm
Cooling: Air
Compression Ratio: 8.3:1
Fuel System: 42.5mm diaphragm-type CV carburetor
Ignition: Solid-state CD with electronic advance
Transmission: Five-speed
Final Drive: #520 O-ring-sealed chain; 15T/45T
Front Suspension: 43mm air-adjustable axle Showa® cartridge fork with 16-position compression-damping adjustability; 11.6-in. of travel
Rear Suspension: Pro-Link® Showa single-shock with spring-preload, 20-position compression- and 20-position rebound-damping adjustability; 11.0-in. of travel
Front Brakes: Single disc with twin-piston caliper
Rear Brakes: Single disc
Front Tire: 3.00-21
Rear Tire: 4.60-18
Wheelbase: 57.3 in.
Seat Height: 37.0 in.
Rake: 27.0 deg.
Trail: 4.0 in.
Fuel Capacity: 2.8 gal., including 0.6-gal. reserve
MPG: 52 MPG - Miles per gal. values are calculated estimates of fuel consumed during laboratory exhaust emissions tests specified by the EPA, not during on road riding. Use for comparison purposes only. Your actual mileage will vary depending on how you ride and maintain your vehicle, weather, road conditions, tire pressure, cargo and accessories, rider and passenger weight, and other factors.
Dry Weight: Curb Weight: 346 lb.
Colors: Red
