Engine Type: Single-Cylinder
Displacement: 14.2 cu. in. (233 cc)
Bore and Stroke: Bore: 2.64 in. (67 mm); Stroke: 2.6 in. (66 mm)
Cooling: Air
Compression Ratio: 9.4:1
Fuel System: Gas
Transmission: Manual
Front Suspension: Inverted Fork
Rear Suspension: Twin Sided Swing Arm
Front Brakes: Hydraulic Disc
Rear Brakes: Hydraulic Disc
Front Tire: IRC RX-01 Road Winner: 110/70-17
Rear Tire: IRC RX-01 Road Winner: 120/70-17
Wheelbase: 53.7 in. (1364 mm)
Seat Height: 33 in. (838.2 mm)
Rake: 24.9
Trail: 3 in. (76.2 mm)
Fuel Capacity: 2 gal. (7.6 L)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
