Engine Type: 90-degree, four-stroke V-twin, SOHC, four valves per cylinder
Displacement: 749 cc
Bore x Stroke: 85 x 66 mm
Cylinders: V-twin
Engine Cooling: Liquid-cooled
Fuel System: Fuel Injection; (2) 36 mm Mikuni throttle bodies
Starting System: Electric
Front Suspension: Dual A-arm
Front Travel: 6.7 in.
Front Brake Type: Dual hydraulic 200mm discs with 2-piston calipers
Front Tires: AT25x8-12
Rear Suspension: Fully Independent, dual A-arm
Rear Travel: 7.9 in.
Rear Brake Type: Sealed, oil-bathed, multi-disc
Rear Tires: AT25x10-12
Frame: Double-cradle, tubular steel
Dry Weight: Curb weight: 652.7 lbs
Front Rack Capacity: 88 lbs
Rear Rack Capacity: 176 lbs
Towing Capacity: 1,250 lbs
Fuel Capacity: 5.0 gal
Ground Clearance: 9.7 in.
Machine Dimensions (LxWxH): 86.4 x 45.9 x 48.5 in.
Wheelbase: 50.6 in.
Final Drive: Selectable four-wheel drive with Variable Front Differential Control, shaft
Transmission: Continuously variable belt-drive transmission with high and low range, plus reverse, and Kawasaki Engine Brake Control
Speedometer: Standard
Odometer: Standard
Lighting: (4) 40W headlights, 5W taillight, 21W stoplight
Colors: Woodsman Green, Sunbeam Red, Lime Green, Super Black and Dark Royal Red
