Engine Type: V-twin, SOHC, 8-valve (4-valve/cylinder)
Displacement: 799.9 cc
Bore and Stroke: 91 x 61.5 mm
Cooling: Liquid-cooled
Fuel System: iTC™ with EFI and 54mm Throttle Body, 2 Siemens8 VDO injectors
Ignition: Electric
Front Suspension: Double A-arm with dive-control geometry/Motion Control shocks
Front Brakes: Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Front Tire: Carlisle Black Rock 27 x 9 x 12 in. (686 x 229 x 305 mm)
Rear Suspension: Torsional Trailing arm Independent (TTI) with external sway bar/ Motion Control shocks
Rear Brakes: Single 214 mm ventilated disc brake with hydraulic twin-piston caliper
Rear Tire: Carlisle Black Rock 27 x 9 x 12 in. (686 x 229 x 305 mm)
Dry Weight: 1,287 lbs. (584 kg)
Wheelbase: 75.8 in. (1,925 mm)
Front Travel: 10 in. (254 mm)
Rear Travel: 10 in. (254 mm)
Ground Clearance: 11 in. (279 mm)
Fuel Capacity: 10 US gal. (37.8 l)
Box Capacity:
Towing Capacity: 1,500 lbs. (680 kg)
Transmission: CVT, sub-transmission with high, low, park, neutral & reverse. Standard engine braking
Drive System: Selectable 2WD/4WD shaft driven with Visco-Lok front differential
Speedometer: Yes
Tachometer: Yes
Odometer: Yes
Colors: Yellow
