Factory Warranty Until 3/23/27 - Eligible for Extended Warranty Engine Type: D1803-CR-TE4
Engine Manufacturer: Kubota
Horsepower: Gross: 40.4 HP (30.1 kW); Net: 38.9 HP (29.0 kW)
Rated RPM: 2200 RPM
Fuel Capacity: 16.9 gal. (64 L)
Length: 16 ft. 8.2 in. (5085 mm)
Width: 5 ft. 6.9 in. (1700 mm)
Height: Canopy: 8 ft. 1.8 in. (2485 mm); Cab: 8 ft. 1.8 in. (2485 mm)
Weight: Rubber Canopy: 9195 lb. (4170 kg), Cab: 9500 lb. (4310 kg); Steel Canopy: 9350 lb. (4240 kg), Cab: 9655 lb. (4380 kg)
Hydraulic System: Pump capacity: 24.4 gpm (92.4 rpm); Auxiliary Hydraulic AUX1: 17.2 GPM (65 L/min); AUX2: 9.8 GPM (37 L/min)
Speed: Low: 1.8 mph (2.9 km/h); High: 3.1 mph (5.0 km/h)
