2026 Yamaha Grizzly EPS XT-R

Engine Type: Single-Cylinder
Displacement: 41.8 cu. in. (686 cc)
Bore x Stroke: Bore: 4.02 in. (102 mm); Stroke: 3.31 in. (84 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent Double Wishbone
Front Travel: 7.6 in. (193 mm)
Front Brake Type: Dual Hydraulic Disc
Front Tires: Maxxis® Zilla AT27 x 10 - 14 MU01
Rear Suspension: Independent Double Wishbone
Rear Travel: 9.1 in. (232 mm)
Rear Brake Type: Dual Hydraulic Disc
Rear Tires: Maxxis® Zilla AT27 x 10 - 14 MU01
Frame: Steel
Towing Capacity: 1322 lb. (600 kg.)
Fuel Capacity: 4.8 gal. (18 L)
Ground Clearance: 11.8 in. (300 mm)
Machine Dimensions (LxWxH): L: 81.5 in. (2070 mm); W: 49.2 in. (1250 mm); H: 50 in. (1270 mm)
Wheelbase: 49.2 in. (1250 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Standard
