Engine Type: SOHC, 4-valve, single
Displacement: 686cc
Bore and Stroke: 102 mm x 84 mm
Cooling: Liquid
Compression Ratio: 10.0: 1
Fuel System: Mikuni 44 mm throttle body F.I.
Ignition: TCI
Front Suspension: Independent double wishbone
Front Brakes: Dual 207 mm discs / twin piston calipers
Front Tire: AT25 x 8-12
Rear Suspension: Independent double wishbone with anti-sway bar
Rear Brakes: Dual 207 mm discs / twin piston calipers / Shaft mounted parking brake
Rear Tire: AT25 x 10-12
Dry Weight: 618 kg (1,363 lb.)
Wheelbase: 2,135 mm (84.1 in.)
Front Travel: 205 mm (8.1 in.)
Rear Travel: 205 mm (8.1 in.)
Ground Clearance: 300 mm (11.8 in.)
Fuel Capacity: 36.7 L (8.1 Imp. gal.)
Box Capacity: 272 kg (600 lb.)
Towing Capacity: 680 kg (1,500 lb.)
Transmission: Yamaha Ultramatic CVT with reverse & On-Command (2WD, 4WD limited slip, 4WD diff-lock)
Colors: Red (steel wheels), Green (steel wheels), Gray (aluminum mag wheels)
