Engine Type: SOHC, single
Displacement: 686 cc
Bore x Stroke: 102 mm x 84 mm
Engine Cooling: Liquid
Fuel System: Mikuni 44 mm throttle body F.I.
Starting System: Electric
Front Travel: 193 mm (7.6 in.)
Front Suspension: Independent double wishbone
Front Brake Type: Dual 220 mm discs / single piston calipers
Front Tires: Maxxis, AT25 x 8-12
Rear Suspension: Adjustable independent double wishbone with anti-sway bar
Rear Travel: 232 mm (9.1 in.)
Rear Brake Type: Multi-Disc wet brake in rear gearcase
Rear Tires: Maxxis, AT25 x 10-12
Dry Weight: Curb Weight: 301 kg (664 lb.)
Front Rack Capacity: 50 kg (110 lb.)
Rear Rack Capacity: 90 kg (198 lb.)
Towing Capacity: 600 kg (1,322 lb.)
Fuel Capacity: 18 L (4 Imp. gal.)
Ground Clearance: 288 mm (11.3 in.)
Machine Dimensions (LxWxH): 2070 mm (81.5 in.) x 1180 mm (46.5 in.) x 1240 mm (48.8 in.)
Wheelbase: 1250 mm (49.2 in.)
Final Drive: Shafts
Transmission: Yamaha Ultramatic CVT with lever operated 2WD - 4WD drive mode selector
Colors: Dark Red (steel wheels)
