Engine Type: 4-stroke, SOHC, Single-cylinder
Displacement: 271 cc
Bore x Stroke: 72.7 x 65.2 mm (2.86 x 2.57 in.)
Engine Cooling: Liquid
Fuel System: Carburettor: CVK32
Starting System: Electric with recoil backup
Front Travel: 131 mm
Front Suspension: Double Wishbone, Wheel Travel: 131 mm (5.16 in.)
Front Brake Type: Disc x 2
Front Tires: AT 22 x 7-10 MAXXIS
Rear Suspension: Swingarm, Wheel Travel: 141 mm (5.55 in.)
Rear Travel: 141 mm
Rear Brake Type: Disc
Rear Tires: AT 22 x 10-10 MAXXIS
Frame: Double tubular, steel
Towing Capacity: 500 lb. (227 kg)
Fuel Capacity: 12 L (3.2 gal.)
Ground Clearance: 155 mm (6.10 in.)
Machine Dimensions (LxWxH): 1915 mm (75.39 in.) x 1080 mm (42.52 in.) x 1170 mm (46.06 in.)
Wheelbase: 1165 mm (45.87 in.)
Final Drive: Shaft 2WD, Reduction Ratio: 4.273
Transmission: 2-speed and reverse, Automatic, Gear Ratios: High 2.926, Low 4.147, Reverse 4.128
