DEMO UNIT Engine Type: 2-stroke
Displacement: 794cc
Bore x Stroke: 85 x 70 mm
Cylinders: 2
Engine Cooling: Liquid
Carburetion: 46 mm dual throttle body batteryless EFI
Ignition: 3D with throttle position sensor
Exhaust: APV with tuned pipe, pipe sensor and stainless steel muffler
Brake Type: Radial master cylinder hydraulic brake / disc on driveshaft
Drive Clutch: Arctic 6 post (rpm sensing)
Driven Clutch: 10.75 in. dia. Arctic (roller cam)
Front Suspension: Arctic Race Suspension with FOX FLOAT 3 shocks
Front Travel: 9 in.
Rear Suspension: M Rear Suspension with tri-hub rear axle system, Arctic Cat (IFP) shock on front arm, FOX FLOAT 2 shock on rear arm
Rear Travel: 15.5 in.
Ski Type: Mountain 6 in.
Ski Stance: 38-39 in. adjustable
Track Type: Power Claw
Track Dimensions: 15 in. W x 153 in. L x 2.60 in. H x 3.00 in. Pitch
Headlight: Dual Halogen Headlight (2-Bulb)
Fuel Capacity: 12 gal.
Windshield: Low
Color: Orange, White
Electric Start: Standard
Hand & Thumb Warmers: Standard
Reverse: Push-Button
Mirrors: Optional
