Engine Type: SOHC 4-stroke, 2-valves
Displacement: 421 cc
Bore x Stroke: 84.5 mm x 75 mm
Engine Cooling: Liquid
Fuel System: Yamaha Fuel Injection (YFI), 34 mm
Starting System: Electric
Front Suspension: Independent double wishbone
Front Travel: 171 mm (6.7 in.)
Front Brake Type: Dual hydraulic disc
Front Tires: AT25 x 8-12
Rear Suspension: Independent double wishbone
Rear Travel: 189 mm (7.4 in.)
Rear Brake Type: Multi-Disc wet brake
Rear Tires: AT25 x 10-12
Dry Weight: Curb Weight: 295 kg (650 lb.)
Front Rack Capacity: 40 kg (88 lb.)
Rear Rack Capacity: 80 kg (176 lb.)
Towing Capacity: 600 kg (1,322 lb.)
Fuel Capacity: 16.8 L (3.7 Imp. Gal)
Ground Clearance: 245 mm (9.6 in.)
Machine Dimensions (LxWxH): 2035 mm (80.1 in.) x 1180 mm (46.5 in.) x 1160 mm (45.7 in.)
Wheelbase: 1240 mm (48.8 in.)
Final Drive: On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft
Transmission: Ultramatic V-Belt with all-wheel engine braking; H, L, N, R, P
Colors: Realtree Edge Camouflage
