Engine Type: SOHC, 2-valve, single
Displacement: 89.9cc
Bore x Stroke: 47 mm x 51.8 mm
Engine Cooling: Air
Fuel System: TK13 mm carburetor
Starting System: Electric with auxillary kick
Front Travel: 126 mm (5 in.)
Front Suspension: Adjustable single A-arm
Front Brake Type: Dual drums
Front Tires: AT 18 x 7-8
Rear Travel: 145 mm (5.7 in.)
Rear Suspension: Adjustable single shock swing arm
Rear Brake Type: Single Drum / Lockable hand lever parking brake
Rear Tires: AT 18 x 9-8
Dry Weight: Curb Weight: 126.5 kg (279 lb.)
Fuel Capacity: 6.4 L
Ground Clearance: 100 mm (3.9 in.)
Machine Dimensions (LxWxH): 1485 mm (58.5 in.) x 1020 mm (40.2 in.) x 955 mm (37.6 in.)
Wheelbase: 1030 mm (40.6 in.)
Final Drive: O-ring chain
Transmission: Fully automatic CVT with reverse
Colors: Team Yamaha Blue; White
