Engine Type: 2-stroke, Single with KIPS
Displacement: 99cc
Bore and Stroke: 52.5 x 45.8 mm
Cooling: Liquid, twin radiators
Compression Ratio: 10.2 (low speed), 8.7 (high speed)
Fuel System: Keihin PWK28 carburetor
Ignition: Digital-CDI
Front Suspension: 36 mm inverted telescopic cartridge fork with 20-way compression damping
Front Brakes: Single 220 mm disc
Front Tire: 70/100-19
Rear Suspension: Uni-Trak single-shock system with 24-way compression and 21-way rebound damping, plus adjustable spring preload
Rear Brakes: Single 184 mm disc
Rear Tire: 90/100-16
Dry Weight: Curb Weight: 77 kg (157 lb.)
Fuel Capacity: 5 L (1.21 gal.)
Wheelbase: 1,310 mm (50.8 in.)
Ground Clearance: 330 mm (13.0 in.)
Seat Height: 870 mm (34.3 in.)
Trail: 108 mm (4.1 in.)
Rake: 29°
Transmission: 6-speed, constant mesh, return shift
Final Drive: Chain
Colors: Lime Green
