Engine Type: 2-stroke
Displacement: 794cc
Bore x Stroke: 85 x 70 mm
Cylinders: 2
Engine Cooling: Liquid
Carburetion: 46 mm dual throttle body batteryless EFI
Ignition: 3D with throttle position sensor
Exhaust: APV with tuned pipe, pipe sensor and stainless steel muffler
Brake Type: Radial master cylinder hydraulic brake / disc on driveshaft
Drive Clutch: Arctic 6 post (rpm sensing)
Driven Clutch: 10.75 in. (27.3 cm) dia. Arctic (roller cam)
Front Suspension: Arctic Race Suspension with FOX FLOAT 3 shocks and sway bar
Front Travel: 10 in. (25.4 cm)
Rear Suspension: FasTrack Rear Suspension with tri-hub rear axle system, FOX FLOAT 3 rear-arm shock, Arctic Cat (IFP) front-arm shock
Rear Travel: 14.5 in. (36.8 cm)
Ski Type: Mountain 6 in. (15.2 cm)
Ski Stance: 42-43 in. (106.7-109 cm) adjustable
Track Type: Cobra
Track Dimensions: 15 in. (38.1 cm) x 141 in. (258.1 cm) x 2.25 in. (4.1 cm)
Speedometer: Standard: Digital/Analog
Tachometer: Standard: Digital
Odometer: Standard: Digital
Headlight: Dual Halogen Headlight (2-Bulb)
Fuel Capacity: 11.7 gal. (44.3 L)
Windshield: Race-Height
Color: Orange
Electric Start: Optional
Hand & Thumb Warmers: Standard
Reverse: Push-Button
Mirrors: Optional
