Engine Type: 4-stroke, Single
Displacement: 233cc
Bore and Stroke: 67 x 66 mm
Cooling: Air
Compression Ratio: 9.4:1
Fuel System: Fuel injection (32 x 1)
Ignition: B&C (TCBI EL. ADV. D.)
Front Suspension: 37 mm telescopic fork
Front Brakes: Single 240 mm petal disc
Front Tire: 80/100-21 51M
Rear Suspension: New Uni Trak with adjustable preload
Rear Brakes: Single 220 mm petal disc
Rear Tire: 100/100-18 59M
Dry Weight: Curb Weight: 115 kg (253.5 lb.)
Fuel Capacity: 6.6 L (1.5 gal.)
Wheelbase: 1360 mm
Ground Clearance: 300 mm
Seat Height: 925 mm
Trail: 113 mm
Rake: 26.5°
Transmission: 6-speed
Final Drive: Chain
Colors: Lime Green
