Engine Type: SOHC 4-stroke
Displacement: 686cc
Bore x Stroke: 102 mm x 84 mm
Engine Cooling: Liquid
Fuel System: Yamaha Fuel Injection (YFI), 44 mm
Starting System: Electric
Front Suspension: Independent double wishbone
Front Travel: 180 mm (7.1 in.)
Front Brake Type: Dual hydraulic disc
Front Tires: Maxxis MU19, AT25 x 8-12
Rear Suspension: Adjustable independent double wishbone with anti-sway bar
Rear Travel: 232 mm (9.1 in.)
Rear Brake Type: Multi-Disc wet brake
Rear Tires: Maxxis MU20, AT25 x 10-12
Dry Weight: Curb Weight: 311 kg (686 lb.)
Front Rack Capacity: 50 kg (110 lb.)
Rear Rack Capacity: 90 kg (198 lb.)
Towing Capacity: 600 kg (1,322 lb.)
Fuel Capacity: 18 L
Ground Clearance: 274 mm (10.8 in.)
Machine Dimensions (LxWxH): 2070 mm (81.5 in.) x 1180 mm (46.5 in.) x 1240 mm (48.8 in.)
Wheelbase: 1250 mm (49.2 in.)
Final Drive: On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft
Transmission: Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
Colors: Tactical Green
