RAPTOR 125 RACING BLUE 2011 Engine Type: 4-stroke, SOHC, air-cooled, single
Displacement: 124cc
Bore x Stroke: 49 x 66mm
Cylinders: Single
Engine Cooling: Air-Cooled
Fuel System: Mikuni VM18SH
Starting System: Ignition: CDI ; Starting: Electric
Front Suspension: Independent wishbone, 2.8-in travel
Front Brake Type: Dual sealed drum
Front Tires: 20 x 7-8
Rear Suspension: Swing-arm, 3.2-in travel
Rear Brake Type: Sealed drum
Rear Tires: 22 x 10-8
Dry Weight: 139 kg (306 lbs.)
Fuel Capacity: 7.6 l
Ground Clearance: 145mm (5.7 in.)
Machine Dimensions (LxWxH): 1,700mm x 990mm x 980mm (66.9 in. x 39 in. x 38.6 in.)
Wheelbase: 1,080mm (42.5 in.)
Final Drive: O-ring chain
Transmission: V-belt, automatic with reverse
Colors: Dark Green
