Engine Type: 2-stroke
Displacement: 599cc
Bore x Stroke: 73.8 x 70 mm
Cylinders: 2
Engine Cooling: Liquid
Carburetion: 47 mm dual throttle body batteryless EFI
Ignition: 3D sequential fire, throttle position sensor
Exhaust: APV with tuned pipe, pipe sensor and stainless steel muffler
Brake Type: Race radial master cylinder hydraulic brake
Drive Clutch: Arctic 6 post (rpm sensing)
Driven Clutch: 10.75 in. (27.3 cm) dia. Arctic (roller cam)
Front Suspension: Arctic Race Suspension with FOX FLOAT 3 shocks and sway bar
Front Travel: 10 in. (25.4 cm)
Rear Suspension: Slide-Action Suspension with tri-hub rear axle system, coupling blocks, Torque-Sensing Link, adjustable torsion springs, Arctic Cat (IFP) shocks (2" dia. rear shock)
Rear Travel: 13.5 in. (34.3 cm)
Ski Type: Trail 6 in. (15.2 cm)
Ski Stance: 42-43 in. (106.7-109 cm) adjustable
Track Type: Ripsaw II
Track Dimensions: 15 in. (38.1 cm) x 137 in. (348 cm) x 1.25 in. (3.2 cm)
Speedometer: Standard: Digital
Tachometer: Standard: Digital
Odometer: Standard: Digital
Headlight: Dual Halogen Headlight (2-Bulb)
Fuel Capacity: 11.7 gal. (44.3 L)
Windshield: Race-Height
Color: Team Arctic Green, Orange
Electric Start: Standard
Hand & Thumb Warmers: Standard
Reverse: Push-Button
Mirrors: Optional
