Engine Type: SOHC, 2-valve, single
Displacement: 421 cc
Bore x Stroke: 84.5 mm x 75 mm
Engine Cooling: Liquid
Fuel System: Mikuni 34 mm throttle body F.I.
Starting System: Electric
Front Suspension: Adjustable independent double wishbone
Front Travel: 171 mm (6.7 in.)
Front Brake Type: Dual 220 mm discs / single piston calipers
Front Tires: AT25 x 8-12
Rear Suspension: Adjustable independent double wishbone with anti-sway bar
Rear Travel: 189 mm (7.4 in.)
Rear Brake Type: Sealed multi-disc wet brake
Rear Tires: AT25 x 10-12
Dry Weight: Curb Weight: 295 kg (650.4 lb.)
Front Rack Capacity: 40 kg (88 lb.)
Rear Rack Capacity: 80 kg (176 lb.)
Towing Capacity: 600 kg (1,322 lb.)
Fuel Capacity: 14 L (3.1 Imp. gal.)
Ground Clearance: 245 mm (9.6 in.)
Machine Dimensions (LxWxH): 2035 mm (80.1 in.) x 1180 mm (46.5 in.) x 1160 mm (45.7 in.)
Wheelbase: 1240 mm (48.8 in.)
Final Drive: Shaft
Transmission: Yamaha Ultramatic (fully automatic) CVT with push button On-Command (2WD & 4WD limited slip)
Colors: Green, Blue, Beige with Camouflage
