Engine Type: 4-stroke
Displacement: 1056cc
Bore x Stroke: 98 x 70 mm
Cylinders: 2 - Turbocharged
Engine Cooling: Liquid
Carburetion: 46 mm single throttle body EFI
Ignition: Full transistor
Exhaust: Turbocharger with stainless steel muffler
Brake Type: Radial master cylinder hydraulic brake / disc on driveshaft
Drive Clutch: Arctic 6 post (rpm sensing)
Driven Clutch: 10.75 in. dia. Arctic (roller cam)
Front Suspension: Arctic Race Suspension with Arctic Cat (IFP) shocks and sway bar
Front Travel: 10 in.
Rear Suspension: FasTrack slide-action suspension with Tri-hub rear axle system, coupling blocks, torque sensing link, adjustable torsion springs, Arctic Cat (IFP) shocks
Rear Travel: 13.5 in.
Ski Type: Trail 6 in.
Ski Stance: 42-43 in. adjustable
Track Type: Ripsaw II
Track Dimensions: 15 in. W x 137 in. L x 1.25 in. H x 2.86 in. Pitch
Headlight: Dual Halogen Headlight (2-Bulb)
Fuel Capacity: 10.6 gal.
Windshield: Mid
Color: Green, Black
Electric Start: Standard
Hand & Thumb Warmers: Standard
Reverse: Push-Button
Mirrors: Optional
