Engine Type: V Twin
Displacement: 59.5 cu. in. (976 cc)
Bore and Stroke: Bore: 3.58 in. (91 mm); Stroke: 2.95 in. (75 mm)
Cooling: Liquid
Fuel System: Gas
Front Suspension: Independent Double A-Arm
Front Brakes: Dual Hydraulic Disc
Front Tire: Maxxis® Bighorn 2.0 27 x 9-12
Rear Suspension: Independent
Rear Brakes: Dual Hydraulic Disc
Rear Tire: Maxxis® Bighorn 2.0 27 x 11-12
Dry Weight: 1405 lb. (637.3 kg.)
Wheelbase: 90.6 in. (2301 mm)
Front Travel: 11.5 in. (292 mm)
Rear Travel: 12 in. (305 mm)
Ground Clearance: 12 in. (305 mm)
Fuel Capacity: 10 gal. (38 L)
Box Capacity: 300 lbs. (136 kg.)
Towing Capacity: 1500 lb. (680 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
