Engine Type: 4-stroke, single cylinder
Displacement: 49cc
Bore x Stroke: 1.417 in. x 1.913 in. (36.0 mm x 48.6 mm)
Engine Cooling: Air
Fuel System: Mikuni VM13, single carburetor
Starting System: Electric and back-up recoil
Front Suspension: Independent, swing axle, coil spring, oil damped
Front Brake Type: Twin drum brakes
Front Tires: AT16 × 8-7, tubeless type x 2
Rear Suspension: Swingarm type, coil spring, oil damped
Rear Brake Type: Single drum brake
Rear Tires: AT16 × 8-7, tubeless type x 2
Dry Weight: Curb Weight: 174 lb. (79 kg)
Fuel Capacity: 0.7 US gal. (2.7 L)
Ground Clearance: 4.7 in. (120 mm)
Machine Dimensions (LxWxH): 50.0 in. (1270 mm) x 29.9 in. (760 mm) x 30.1 in. (765 mm)
Wheelbase: 32.7 in. (830 mm)
Drive Train: 2WD
Final Drive: Chain, DID 415, 82 links
Transmission: CVT automatic
Lighting: N/A
Colors: Champion Yellow No. 2
