Engine Type: Single-Cylinder
Displacement: 41.9 cu. in. (686 cc)
Bore and Stroke: Bore: 4.02 in. (102 mm); Stroke: 3.31 in. (84 mm)
Cooling: Liquid
Compression Ratio: 10.0:1
Fuel System: Gas
Front Suspension: Independent Double Wishbone
Front Brakes: Dual Hydraulic Disc
Front Tire: AT25 X 8-12
Rear Suspension: Independent Double Wishbone
Rear Brakes: Dual Hydraulic Disc
Rear Tire: AT25 X 10-12
Wheelbase: 84.1 in. (2136 mm)
Front Travel: 8.1 in. (205.7 mm)
Rear Travel: 8.1 in. (205.7 mm)
Ground Clearance: 11.8 in. (300 mm)
Fuel Capacity: 9.7 gal. (36.7 L)
Box Capacity: 600 lbs. (272.2 kg.)
Towing Capacity: 1500 lb. (680.4 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Standard
