Engine Type: Single-Cylinder
Displacement: 25.7 cu. in. (421 cc)
Bore x Stroke: Bore: 3.33 in. (84.5 mm); Stroke: 2.96 in. (75 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent Double Wishbone
Front Travel: 6.7 in. (171 mm)
Front Brake Type: Dual Hydraulic Disc
Front Tires: AT25 x 8 - 12
Rear Suspension: Independent Double Wishbone
Rear Travel: 7.4 in. (189 mm)
Rear Brake Type: Sealed Oil Bath Multi-Disc
Rear Tires: AT25 x 10 - 12
Frame: Steel
Towing Capacity: 1322 lb. (600 kg.)
Fuel Capacity: 3.7 gal. (14 L)
Ground Clearance: 9.6 in. (245 mm)
Machine Dimensions (LxWxH): L: 80.1 in. (2035 mm); W: 46.5 in. (1180 mm); H: 45.7 in. (1160 mm)
Wheelbase: 48.8 in. (1240 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Standard
