Engine Type: Single-Cylinder
Displacement: 5.2 cu. in. (84.9 cc)
Bore and Stroke: Bore: 1.85 in. (47 mm); Stroke: 1.93 in. (49 mm)
Cooling: Liquid
Fuel System: Gas / Oil Premix
Front Suspension: Inverted Fork
Front Brakes: Hydraulic Disc
Front Tire: Maxxis® MX-ST 70/100 R19 40M
Rear Suspension: Twin Sided Swing Arm
Rear Brakes: Hydraulic Disc
Rear Tire: Maxxis® MX-ST 90/100 R16 49M
Dry Weight: 149.9 lb. (68 kg.)
Fuel Capacity: 1.4 gal. (5.2 L)
Wheelbase: 50.8 in. (1290 mm)
Ground Clearance: 14.3 in. (362 mm)
Seat Height: 34.4 in. (875 mm)
Rake: 24
Transmission: Manual
Final Drive: 3.29
