Engine Type: V Twin
Displacement: 37.6 cu. in. (617 cc)
Bore and Stroke: Bore: 2.99 in. (76 mm); Stroke: 2.68 in. (68 mm)
Cooling: Liquid
Compression Ratio: 10.3:1
Fuel System: Gas
Front Suspension: McPherson Strut
Front Brakes: Sealed Hydraulic Drum
Front Tire: Duro: 23 x 11-10
Rear Suspension: De Dion Semi Independent
Rear Brakes: Sealed Hydraulic Drum
Rear Tire: Duro: 23 x 11-10
Wheelbase: 85.2 in. (2164.1 mm)
Front Travel: 3.9 in. (99.1 mm)
Rear Travel: 2.8 in. (71.1 mm)
Ground Clearance: 7.1 in. (180.3 mm)
Fuel Capacity: 6.3 gal. (23.8 L)
Box Capacity: 800 lbs. (362.9 kg.)
Towing Capacity: 1200 lb. (544.3 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Optional
