Engine Type: Liquid-cooled, SOHC 4-stroke
Displacement: 686 cc
Bore x Stroke: 102 mm x 84 mm
Fuel System: Yamaha Fuel Injection (YFI), 44 mm
Starting System: Electric
Front Suspension: Independent double wishbone / 180 mm (7.1 in.) of wheel travel
Front Brake Type: Dual hydraulic disc
Front Tires: Maxxis MU19, AT25 x 8-12
Rear Suspension: Adjustable independent double wishbone with anti-sway bar / 232 mm (9.1 in.) of wheel travel
Rear Brake Type: Multi-Disc wet brake
Rear Tires: Maxxis MU20, AT25 x 10-12
Dry Weight: 299 kg (659 lb)
Front Rack Capacity: 50 kg (110 lb)
Rear Rack Capacity: 90 kg (198 lb)
Towing Capacity: 600 kg (1,322 lb)
Fuel Capacity: 18 L
Ground Clearance: 274 mm (10.8 in.)
Wheelbase: 1250 mm (49.2 in.)
Final Drive: Lever-operated 2WD/4WD; shaft
Transmission: Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
Colors: Tactical Green
