Engine Type: Single-Cylinder
Displacement: 6.8 cu. in. (112 cc)
Cylinders: 1
Bore x Stroke: Bore: 2.4 in. (61 mm); Stroke: 2.28 in. (57.8 mm)
Engine Cooling: Air
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent A-Arm
Front Travel: 5 in. (127 mm)
Front Brake Type: Drum
Front Tires: Duro: 19 x 7 - 8
Rear Travel: 6 in. (152 mm)
Rear Suspension: Swing Arm
Rear Brake Type: Drum
Rear Tires: Duro: 18 x 9.5 - 8
Frame: Steel
Dry Weight: 289 lb. (131 kg.)
Fuel Capacity: 2 gal. (7.8 L)
Ground Clearance: 3.5 in. (89 mm)
Machine Dimensions (LxWxH): L: 61.3 in. (1556 mm); W: 36.8 in. (933 mm); H: 38.5 in. (978 mm)
Wheelbase: 41.5 in. (1054 mm)
Drive Train: Continuously Variable (CVT)
