Phone: 807.623.5042
Plus Freight and PDI
12m factory warranty plus FREE SPP24 Engine Type: Single-Cylinder
Displacement: 30 cu. in. (493 cc)
Bore x Stroke: Bore: 3.4 in. (87.5 mm); Stroke: 3.2 in. (82 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent Double A-Arm
Front Travel: 6.7 in. (170.2 mm)
Front Brake Type: Dual Hydraulic Disc
Front Tires: Carlisle AT 25 X 8-12
Rear Suspension: Independent Double A-Arm
Rear Travel: 7.7 in. (195.6 mm)
Rear Brake Type: Sealed Oil Bath Multi-Disc
Rear Tires: Carlisle AT 25 X 10-12
Frame: Steel
Towing Capacity: 1322 lb. (599.7 kg.)
Fuel Capacity: 4.6 gal. (17.5 L)
Ground Clearance: 10.2 in. (260 mm)
Machine Dimensions (LxWxH): L: 84.6 in. (2150 mm); W: 47.8 in. (1215 mm); H: 50.6 in. (1285 mm)
Wheelbase: 50.6 in. (1285 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Standard
