Engine Type: Single-Cylinder
Displacement: 36.6 cu. in. (600 cc)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent Double A-Arm
Front Travel: 8.7 in. (222 mm)
Front Brake Type: Dual Hydraulic Disc
Front Tires: AT 25 X 8-12
Rear Suspension: Independent Double A-Arm
Rear Travel: 8.7 in. (222 mm)
Rear Brake Type: Hydraulic Disc
Rear Tires: AT 25 X 10-12
Frame: Steel
Dry Weight: 836.1 lb. (379.3 kg.)
Towing Capacity: 1050 lb. (476 kg.)
Fuel Capacity: 5.7 gal. (21.6 L)
Ground Clearance: 11.3 in. (287 mm)
Machine Dimensions (LxWxH): L: 91.1 in. (2314 mm); W: 48.8 in. (1239 mm); H: 50.1 in. (1273 mm)
Wheelbase: 58 in. (1473 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
