Engine Type: Single-Cylinder
Displacement: 11.7 cu. in. (192 cc)
Bore x Stroke: Bore: 2.76 in. (70 mm); Stroke: 1.97 in. (50 mm)
Cylinders: 1
Engine Cooling: Air / Fan
Carburetion: Carburetor
Brake Type: Hydraulic Disc
Driven Clutch: Continuously Variable (CVT)
Front Suspension: Independent Double Wishbone
Front Travel: 4.5 in. (114.3 mm)
Rear Travel: 8.5 in. (215.9 mm)
Ski Type: Plastic
Ski Stance: Min: 29.5 in. (749.3 mm); Max: 31.5 in. (800.1 mm)
Track Type: Cobra Track
Track Dimensions: W: 10 in. (254 mm); L: 93 in. (2362.2 mm); Lug Height: 1 in. (25.4 mm)
Fuel Capacity: 2.2 gal. (8.3 L)
Dry Weight: 214 lb. (97.1 kg.)
Windshield: Standard
Electric Start: Electric
Reverse: No
