Engine Type: In-Line
Displacement: 60.9 cu. in. (999 cc)
Bore and Stroke: Bore: 3.66 in. (93 mm); Stroke: 2.89 in. (73.5 mm)
Cooling: Liquid
Compression Ratio: 11:1
Fuel System: Gas
Front Suspension: Independent Double A-Arm
Front Brakes: Hydraulic Disc
Front Tire: Trail Master X/T 2.0: 30 x 10-14
Rear Suspension: Independent
Rear Brakes: Hydraulic Disc
Rear Tire: Trail Master X/T 2.0: 30 x 10-14
Dry Weight: 1865 lb. (846 kg.)
Wheelbase: 117 in. (2972 mm)
Front Travel: 20 in. (508 mm)
Rear Travel: 20 in. (508 mm)
Ground Clearance: 14.5 in. (368 mm)
Fuel Capacity: 9.5 gal. (36 L)
Box Capacity: 300 lbs. (136 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
