2025 Honda PIONEER 1000-5 DELUXE

Engine Type: Parallel Twin
Displacement: 60.9 cu. in. (999 cc)
Bore and Stroke: Bore: 3.62 in. (92 mm); Stroke: 2.96 in. (75.1 mm)
Cooling: Liquid
Compression Ratio: 10:1
Fuel System: Gas
Front Suspension: Independent Double Wishbone
Front Brakes: Hydraulic Disc
Front Tire: Armstrong Dirt Master 2.0: 27 x 9-14
Rear Suspension: Independent Double Wishbone
Rear Brakes: Hydraulic Disc
Rear Tire: Armstrong Dirt Master 2.0: 27 x 11-14
Wheelbase: 80.2 in. (2037.1 mm)
Front Travel: 10.6 in. (268 mm)
Rear Travel: 10 in. (254 mm)
Ground Clearance: 12.4 in. (315 mm)
Fuel Capacity: 7.9 gal. (29.9 L)
Box Capacity: 1000 lbs. (226.8 kg.)
Towing Capacity: 2500 lb. (1134 kg.)
Drive System: Manual / Automatic Clutch
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
