Engine Type: Single-Cylinder
Displacement: 25.6 cu. in. (420 cc)
Bore x Stroke: Bore: 3.41 in. (86.5 mm); Stroke: 2.82 in. (71.5 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent Double Wishbone
Front Travel: 6.7 in. (170 mm)
Front Brake Type: Dual Hydraulic Disc
Front Tires: Maxxis® 24 x 8-12
Rear Travel: 6.7 in. (170 mm)
Rear Suspension: Swing Arm
Rear Brake Type: Sealed Drum
Rear Tires: Maxxis® 24 x 10-11
Frame: Steel
Towing Capacity: 848 lb. (384.7 kg.)
Fuel Capacity: 3.9 gal. (14.8 L)
Ground Clearance: 7.1 in. (180.3 mm)
Machine Dimensions (LxWxH): L: 82.8 in. (2103.1 mm); W: 47.4 in. (1204 mm); H: 46.2 in. (1173.5 mm)
Wheelbase: 50 in. (1270 mm)
Drive Train: Manual
Speedometer: Standard
Odometer: Standard
