Engine Type: Single-Cylinder
Displacement: 30.4 cu. in. (499 cc)
Bore x Stroke: Bore: 3.66 in. (93 mm); Stroke: 2.9 in. (73.6 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Suspension: McPherson Strut
Front Travel: 8.2 in. (208 mm)
Front Brake Type: Hydraulic Disc
Front Tires: Wanda: 25 x 8-12 P373
Rear Suspension: Independent Double A-Arm
Rear Travel: 9.5 in. (241 mm)
Rear Brake Type: Hydraulic Disc
Rear Tires: Wanda: 25 x10-12 P373
Frame: Steel
Dry Weight: 720 lb. (327 kg.)
Towing Capacity: 1350 lb. (612 kg.)
Fuel Capacity: 4.5 gal. (17 L)
Ground Clearance: 11.5 in. (290 mm)
Machine Dimensions (LxWxH): L: 83 in. (2108 mm); W: 48 in. (1219 mm); H: 47 in. (1194 mm)
Wheelbase: 50.5 in. (1283 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
