Engine Type: V4 Granturismo, V4 - 90 deg., 4 valves per cylinder, counter-rotating crankshaft, Twin Pulse firing order
Displacement: 1,158 cc (71 cu. in.)
Bore and Stroke: 83 x 53.5 mm
Cooling: Liquid
Compression Ratio: 14.0 : 1
Fuel System: Electronic fuel injection system, Øeq 46 mm elliptical throttle bodies with Ride-by-Wire system
Transmission: 6 speed with Ducati Quick Shift up/down
Final Drive: Chain, front sprocket z16, rear sprocket z43
Front Suspension: Ø 50 mm fully adjustable usd fork
Rear Suspension: Fully adjustable monoshock, aluminium single-sided swingarm
Front Brakes: Ø 265 mm disc, Brembo 2-piston floating calliper, Cornering ABS
Rear Brakes: Ø 265 mm disc, Brembo 2-piston floatinØ 265 mm disc, Brembo 2-piston floating calliper, Cornering ABS
Front Tire: Pirelli Diablo Rosso III, 120/70 ZR17
Rear Tire: Pirelli Diablo Rosso III, 240/45 ZR17
Wheelbase: 62.7 in. (1,593 mm)
Seat Height: 31.1 in. (790 mm)
Rake: 26 deg.
Trail: 4.4 in. (112 mm)
Fuel Capacity: 5.3 US gal. (20 L)
Dry Weight: 465 lb. (211 kg)
Colors: Ducati Red
