Engine Type: Single-Cylinder
Displacement: 15.3 cu. in. (250 cc)
Bore x Stroke: Bore: 2.8 in. (71 mm); Stroke: 2.48 in. (63 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric / Kick
Front Travel: 5.5 in. (140 mm)
Front Suspension: Double A-Arm
Front Brake Type: Dual Hydraulic Disc
Front Tires: Kenda 22 x 7 - 10
Rear Suspension: Swing Arm
Rear Travel: 6.7 in. (170 mm)
Rear Brake Type: Hydraulic Disc
Rear Tires: Kenda 20 x 11 - 9
Frame: Steel
Dry Weight: 429 lb. (195 kg.)
Fuel Capacity: 3.3 gal. (12.5 L)
Ground Clearance: 4.5 in. (114 mm)
Machine Dimensions (LxWxH): L: 72 in. (1830 mm); W: 40.5 in. (1030 mm); H: 43.5 in. (1105 mm)
Wheelbase: 47 in. (1187 mm)
Drive Train: Continuously Variable (CVT)
