SOLD AS IS. ANY SERVICE WORK OR CHARGES TO UNIT WILL BE ADDED TO SALES PRICE. PRICES ARE SUBJECT TO CHANGE. TAX, TITLE, AND LICENSE FEE TO BE ADDED TO SALES PRICE. IF BUYER IS AG EXEMPT, PROOF WILL NEED TO BE SHOWN AT TIME OF SALE. CONTACT DEALER FOR DETAILS. Engine Type: Four-stroke
Displacement: 401cc
Bore and Stroke: 82 x 76mm
Cooling: Air-cooled single
Compression Ratio: 8.6:1
Fuel System: Nikki 6C1026
Ignition: Magneto and transistor
Front Suspension: Independent, MacPherson strut
Front Brakes: Hydraulic drums, triple sealed
Front Tire: 24x9-10 tubeless
Rear Suspension: Unit swing axle
Rear Brakes: Hydraulic drums, triple sealed
Rear Tire: 24x11-10 tubeless
Dry Weight: 1,010 lb.
Wheelbase: 70.0 in.
Front Travel: 3.1 in.
Rear Travel: 3.1 in.
Ground Clearance: 6.7 in.
Fuel Capacity: 4.1 gal.
Box Capacity: 400 lb.
Towing Capacity: 1,100 lb.
Transmission: Continuously variable transmission with high and low range, plus reverse
Drive System: Shaft-driven selectable four-wheel drive, dual-mode rear differential
Speedometer: Standard
Colors: Dark Royal Red, Woodsman Green
