All Off-Road units are subject to freight and PDI. Engine Type: Single-Cylinder
Displacement: 36.4 cu. in. (597 cc)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Front Travel: 8.7 in. (222 mm)
Front Suspension: Independent Double A-Arm
Front Brake Type: Dual Hydraulic Disc
Front Tires: AT 27 X 9-14
Rear Suspension: Independent Double A-Arm
Rear Travel: 8.7 in. (222 mm)
Rear Brake Type: Hydraulic Disc
Rear Tires: AT 27 X 11-14
Frame: Steel
Dry Weight: 874 lb. (396.4 kg.)
Towing Capacity: 1050 lb. (476 kg.)
Fuel Capacity: 4.8 gal. (18.2 L)
Ground Clearance: 12.3 in. (311 mm)
Machine Dimensions (LxWxH): L: 86.3 in. (2190 mm); W: 48 in. (1219 mm); H: 52.3 in. (1327 mm)
Wheelbase: 52 in. (1320 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
